F-Series 3D Measurement Industrial Videoscope | Remote Visual Inspection Borescope
| Categories | Measuring Endoscopes |
|---|---|
| Brand | Jeet Videoscopes Manufacturer |
| Model | F |
| Diameter | 1.0/1.8/2.2/2.8/3.8/6.0/8.0mm |
| DOF | 10~100mm |
| Sensor | HD image sensor |
| Resolution | HD 1000000 pixels |
| Working length | 2m/3m, customized |
| Material | Abrasion-resistant alloy |
| Articulation | 360° |
| Bending angle | ≤150° |
| Categories | Measuring Endoscopes |
|---|---|
| Brand | Jeet Videoscopes Manufacturer |
| Model | F |
| Diameter | 1.0/1.8/2.2/2.8/3.8/6.0/8.0mm |
| DOF | 10~100mm |
| Sensor | HD image sensor |
| Resolution | HD 1000000 pixels |
| Working length | 2m/3m, customized |
| Material | Abrasion-resistant alloy |
| Articulation | 360° |
| Bending angle | ≤150° |
Description
JEET F SERIES
3D MEASUREMENT VIDEOSCOPE
JEET F-Series 3D Measurement Industrial Videoscope | Remote Visual Inspection Borescope
Utility software
F pro 3D Measurement Videoscope
3D measurement function is a major difficulty in the endoscope industry. Whether the process selection of product appearance materials or the research to the design of software measurement algorithms, JEET R&D team made a large number of feasibility studies and simulation tests.
Measurement function
point-to-point/point-to-line/point to surface depth/ multiple point circumference measurement measurement accuracy ≥ 95%
distance between two points
distance between two points
point -to -plane depth
intelligent operating system, accurate measurement results
High precision and fast global scanning 3D cloud image
Fast global scanning to view 3D
physical cloud image
Vertical depth cloud map, automatic
measurement of maximum depth
3D cloud image XYZ coordinate
display, arbitrary section view, easy to
locate the depth and height difference
of internal defects
the datum plane shifts and the depth value changes in real time
Intelligent Software
Intelligent operation system
Image adjustment: resolution options
Camera parameters setting: brightness/ contrast/ gamma/ ray/ saturation/sharpness
Image effects: auto balance/ negative film/mirror image or rotation/image freezing
Note text: annotation/free drawing/mark
Picture annotation, free drawing
① select pictures or freeze the image ; select “free drawing” icon.
②text note or mark and ；confirm after operation to save
MDI report generation
Portable design
Tube system
