Air Powered, Heavy Duty Tube Cleaner • AWT-100X-ID
Product Features
- Larger wheels for improved mobility
- Sleek, modern design
- Intuitive easy-to-use controls
- Air powered - shock resistant
- Simple to operate - minimal training required
- Stainless steel construction - long life
- Air lubricator - extends motor life
- Speed/torque control - set shaft rotation at optimum speed for each application
- Interchangeable cleaning tools - versatile
- Large wheels - easy to move
- Simultaneous water flush or vacuum - removes deposits
- Foot switch activation - safe operation
- CE certified
- Flexible Shaft Speed: Variable, 500-3,000 rpm
- Motor Power: Up to 4 HP (3 kW) depending upon air pressure and volume
- Air Requirements: Minimum 60 PSI at 85 CFM (4.1 BAR at 2.38 m3/min), Maximum 100 PSI at 130 CFM (7 BAR at 3.64 m3/min)
- Dimensions: 37" (940mm) high x 20" (510mm) wide x 17" (430mm) deep
- Weight: 54 lbs (25 kg) net dry
Product Features
- Larger wheels for improved mobility
- Sleek, modern design
- Intuitive easy-to-use controls
- Air powered – shock resistant
- Simple to operate – minimal training required
- Stainless steel construction – long life
- Air lubricator – extends motor life
- Speed/torque control – set shaft rotation at optimum speed for each application
- Interchangeable cleaning tools – versatile
- Large wheels – easy to move
- Simultaneous water flush or vacuum – removes deposits
- Foot switch activation – safe operation
- CE certified
- Flexible Shaft Speed: Variable, 500-3,000 rpm
- Motor Power: Up to 4 HP (3 kW) depending upon air pressure and volume
- Air Requirements: Minimum 60 PSI at 85 CFM (4.1 BAR at 2.38 m3/min), Maximum 100 PSI at 130 CFM (7 BAR at 3.64 m3/min)
- Dimensions: 37″ (940mm) high x 20″ (510mm) wide x 17″ (430mm) deep
- Weight: 54 lbs (25 kg) net dry
Description
–
Product Overview
The newest AWT-100X Air Powered Tube Cleaner is our most powerful and versatile unit yet. Use it for heavily dirty or scaled tubes, pipes, and more in wet or dry cleaning conditions. It incorporates the same operating principles as the AWT-100. Equipped with a 4 HP (3 kW) drive motor, this machine has the strength needed to clean virtually any tube/pipe 1/4″ (6.4mm) I.D. and up. Flexible shafts and accessories are available for both wet or dry applications.
The AWT-100X uses a cleaning tool mounted to the tip of a flexible shaft. For wet applications, the unit feeds water through the casing to the cleaning tool, flushing out deposits as they are loosened. For dry applications, the GTC-DPA Dry Pickup Attachment and a simultaneous vacuum are used to remove loosened deposits.
