Industrial Vacuum, Wet-Dry, Heavy Duty, Chip/Coolant Recovery w/Tilt Tank • DV-CM7.5-TILT
SKU:
What's Included
DM-CM7.5-TILT-Tank Super ChipMaster Wet-Dry Industrial Vacuum includes:
A 14.5-gallon metal chip basket, 105-gallon liquid collection tank with tilt wheel, handles, casters, and a transfer pump dump valve.
Note: The product does not come with accessories.
What’s Included
DM-CM7.5-TILT-Tank Super ChipMaster Wet-Dry Industrial Vacuum includes:
A 14.5-gallon metal chip basket, 105-gallon liquid collection tank with tilt wheel, handles, casters, and a transfer pump dump valve.
Note: The product does not come with accessories.
Loading...
Description
–
Product Overview
From collection to separation to discharge, the Super Chipmaster® Tilt is a complete soup-to-nuts system. Not only is it a powerful machine that devours chips, swarf, and coolant, it is also a precision instrument that can filter shavings down to 300 microns. Plus, the integrated transfer pump returns filtered coolant to your machine, while an internal basket tilts to dump out the chips and swarf. Simply put, the Super ChipMaster Tilt saves money with minimal effort from you.
Product Features
- Heavy-duty motor
- 105 gallon liquid collection tank
- Coolant level indicator and liquid shut-off feature
- High flow pump tilt-tank
- Metal chip basket
- Cartridge safety filter
- 1-1/2″ or 2″ hoses 3″ dump valve
- Motor Power: Single Motor 6.5 HP regenerative blower motor
- Input Power: 10.3 Amps, 480 V, 50/60 Hz AC
- Power Supply Cord: 30′ (9.15m), 14-4
- Static Water Lift: 160″
- Air Displacement: 170 CFM
- Metal Chip Basket: Filters to 0.05″ (1.3mm) Optional Polypropylene Filter: Filters to 300 microns
- Reverse pump-out system: 50 GPM
- Dimensions: 78″ high x 26″ wide x 60″ deep
- Weight: 265 lbs
